Downhole Drilling Motors
Reduce Non-Productive Time and Service Costs with a Global Leader in Motion Control Technology
Brushless Servo Motors for Downhole Drilling

Why Choose Moog’s Downhole Motors
Reduce your new downhole tool development time, shorten time to market, and increase productivity with Moog Downhole Motors. Available in a variety of sizes with standard configurations, you can develop highly reliable tooling equipped to stand up to high environmental pressures (1,723 bar/25,000 PSI) and max winding temperatures (220°C/ 425°F). All motors are encased in a shock and vibration resistant housing for maximum durability and equipment life.
Your business likely operates in some of the harshest environments on earth and faces an array of equipment challenges. Our proven products are designed and manufactured for long life even in extreme climates and have many of the international certifications necessary for use in hazardous environments globally.
Multiple standard-sized motors are available. If you want to replace your family of motors with custom product specifications, please contact us.
MOTOR SIZE | 8 | 10 | 12 | 16 | 19 | 23 | 28 |
Outer Diamer mm (in) | 21.9 (.862) | 26 (1.02) | 32 (1.26) | 42 (1.65) | 49 (1.93) | 60 (2.36) | 73 (2.88) |
Continuous Output Power Wattage | 48 | 60 | 61 | 500 | 1,040 | 1,500 | 2,500 |
Operating Terminal Peak Voltage | 48 | 48 | 48 | 100 | 100 | 650 | 650 |
